Model
Toyota Corolla, 4 doors
Engine
Turbocharged 4-cylinder in line, transversally installed
Distribution: two overhead camshafts, 16 valves
Displacement: 1995 cc
Bore x stroke: 82.5x93.3 mm
Max. output: 340hp @ 6400 rpm
Max. torque 410nm @ 4400 rpm
Lubrication: wet sump
Transmission
Front-wheel-drive
Gearbox: Sadev 6-speed sequential with paddle shift
Clutch: Alcon double-disc sintered metal
Differential: mechanical limited slip differential
Chassis
Front suspension: Trailing arms, coil springs, gas-filled dampers, anti-roll bar
Rear suspension: Trailing arms, coil springs, gas-filled dampers, anti-roll bar
Steering: electrical power assisted rack and pinion.
Brakes
Dual circuit hydraulic system
Front brakes: four-piston calipers, 378 mm steel ventilated discs
Rear brakes: two-piston calipers, 280 mm steel discs
Dimensions
Length: 4700 mm
Width: 1950 mm
Wheelbase: 2699 mm
BOP
ECU type & Power level: C6 (endurance C4)
Ballast: 0 kg
Minimum racing weight: 1275 kg (endurance 1215 kg)
Ground clearance: 70 mm
Price
TBA
