Model
Renault Mégane IV, 5 doors
Engine
Turbocharged 4-cylinder in line, transversally installed
Distribution: two overhead camshafts, 16 valves
Displacement: 1798 cc
Bore x stroke: 79.7 x 90.1 mm
Max. output 340hp @ 6900 rpm
Max. torque: 420nm @ 3000 rpm
Lubrication: wet sump
Transmission
Front-wheel-drive
Gearbox: 3MO Performance 6-speed sequential with paddle shift
Clutch: SACHS double-plate
Differential: multi-plate limited slip differential
Chassis
Front suspension: McPherson strut, coil springs, gas-filled dampers, anti-roll bar
Rear suspension: Torsion beam axle, coil springs, gas-filled dampers, anti-roll bar
Steering: electrical power assisted rack and pinion
Brakes
Dual circuit hydraulic system
Front brakes: 6-piston calipers, 380 mm steel ventilated discs
Rear brakes: 2-piston calipers, 260 mm steel discs
Dimensions
Length: 4622 mm
Width: 1950 mm
Wheelbase: 2681 mm
BOP
ECU type & Power level: M5 (endurance M3)
Ballast: -10 kg (endurance -5 kg)
Minimum racing weight: 1255 kg (endurance 1205 kg)
Ground clearance: 70 mm
Price
130,000 €
